HIPAA Updates and Threat Models
HIPAA reform seems to lead to published threat models, and that’s going to be a hard change.
The Department of Health and Human Services is working on an upgrade to HIPAA security rules. The update will be complicated and contentious; there’s strong arguments for immediate strengthening of the rules, and there’s a strong argument that most hospitals can’t afford the modernization work. I’m glad that other people need to figure it out.
However, I did want to call out one element, which Ty Greenhalgh spotlights in his HIPAA Overhaul: Preparing for the HIPAA Security Rule NPRM Finalization on Linkedin:
“This requires organizations to map not just the primary software, but the underlying APIs, cloud storage buckets, and third-party code libraries that support it. The hearing participants noted that this level of transparency is often unavailable to the healthcare provider, as vendors frequently treat these sub-system architectures as proprietary information. There is a strong push from the industry to require Business Associates and software vendors to provide a Software Bill of Materials (SBOM) to help hospitals meet this mapping requirement.”
Future state
They’re going to need to start publishing — or at least sharing threat models.
Having already addressed that the future state won’t be the current state, we can disregard that “this level of transparency is often unavailable...” and note: this seems a lot like HHS will be requiring vendors to provide threat models. In contrast to the industry push, SBOMs may be necessary, but they’re not sufficient to understand architecture. SBOMs don’t tell you anything about the arrangement or architecture of a system.
For that, they’re going to need to start publishing, or at least sharing threat models. Last year, Loren Kohnfelder and I published a paper on exactly this topic: Publish Your Threat Model! (A blog-length discussion is here.)
My take is that requiring threat models will be a long term good, and the transition will be a challenge.
The challenge: Medical software makers
Many medical software makers can’t publish or even share a threat model, because they don’t have them.
The first problem is that many medical software makers are where device makers were in 2014, and for many of them their threat models really will be “roadmaps for attackers.” And so in the short to medium term, the medical software maker threat models will likely be shared under NDA, rather than published. That’s a scandal, and it doesn’t need to be that way. For example, recently, Andrew Nesbitt, in his post Not a Security Issue, discovered that roughly 500 open source projects already publish their threat models. If open source projects can do it, so can the major makers of medical software.
In many cases, many medical software makers can’t publish or even share a threat model, because they don’t have them. Creating threat models for existing software will be both daunting and depressing.
The daunting part is a combination of the many shops where no one understands how it works anymore, and that’s magnified by a perception that the threat model needs to go deep. Going super-deep isn’t usually a requirement because older software tends to lack boundaries, and so highly abstract models may be as valuable as more detailed ones.
The depressing part is that the software lacks boundaries, runs with high privilege, and everyone knows those need to change. A threat model can be a great way to start that change, by creating a map of the current state. (The effort to specify the current model often naturally leads to a discussion about the future state).
The challenge: Hospitals
The next step is to discuss how hospitals can effectively start to assess threat models from their vendors current and future vendors. Vendor selection will start to change. A very rough rubric is simply, does the vendor have a public threat model? Vendors who are willing to publish their threat models have more confidence that they’ve done a good job than the ones who have not.
Evaluation can go deeper by looking at the level of detail: A basic threat model here includes a diagram of 5-20 boxes and a list of threats. Does the threat model explain where the endpoints are, where the cloud storage buckets are and how each is protected? Does it map to the SBOM?
After level of detail, the next question could be how many boundaries are in the model: Are there several? If the software operates as a full-trust monolith, that raises the likelihood of future problems having a large blast radius, and shows that any words the vendor said about zero trust were... aspirational(?)
These are obviously broad brush strokes for assessment, and we’re going to have to start figuring it out.
Image by midjourney: “a photograph of stacks of regulations on a desk. There are a few small red cartoonish devils, the size of a quarter or a bit bigger. Some are milling around, scribbling on the paper. Some are peeking out from within the stacks The photo is light and bright”
