Diagrams versus Models (Threat Model Thursday)
What does the new book tell us about the difference between diagrams and models?
Diagrams are the most recognizable tools and deliverables of threat modeling. (Both functions are important: the working tool of a diagram which helps us ask what can go wrong and the deliverable or record which we keep.)
In the first edition, I used the terms “diagram” and “model” nearly interchangeably. In the second, I get more specific about the differences. The dotted line in a diagram is showing a boundary, or the controls, or where there are different principals. And that’s what it is: A bunch of pixels which show the information. In a model, those properties can be specified and acted on. Or even derived: If each element in a model has an attribute about what account it runs with, then you can locate boundaries automatically. You may even be able to infer things about what enforces the boundary. (Unix kernels, AWS IAM, hope, etc.)
In the second edition, I use the term model in two distinct ways: the first is ‘any representation,’ while the second is a formalized construct with technical properties.
Diagrams are easy, fast, and customizable. You can put any shape you want in, you can break rules such as “no data sinks,” you can slap a boundary through the middle of a process, and ain’t no tooling gonna stop you. Models are harder to build: There are questions about the properties that you’re going to compute on later. You can’t fudge as easily. If you want traceability from model to code (or vice versa), you need to spend time connecting the two, and then maintain those connections. If your model breaks the rules, a model checker can warn you, the same way a compiler can (with the same pros and cons).
This dichotomy of “is it worth it” is a theme of the book, because it’s a theme of threat modeling. How do we improve return on investment? The first step is to know where you’re investing. If your diagram tool requires a lot of clicking, then you have to deal with the lots of clicks. And if you need a Visio license before you can start, then there’s both the cash cost and the administrative overhead of getting Visio. Neither adds materially to the quality of a threat model, and so, with investment being higher, the return must be increased as well.
A question I hear all the time is “do we need a diagram if we’re asking an LLM to threat model for us?” The obvious answer is “no.” The LLM will “threat model” (whatever that means) without a diagram, or create one if its token stream stumbles on the idea it needs one. A better question is “how do we get the LLM to do a good job threat modeling?” The answer depends on how you engage with its output. Is a diagram a useful checkpoint? Does it help keep the LLM on task? Does it help the humans review the plan or output? (I know, those things aren’t as fashionable as turning dollars into tokens and burning them.)
LLMs can drive down the costs of diagramming or modeling. Above, I wrote about the work to build models, and that really is changing. The change is unevenly distributed, and its impact is hard to see right now, but overarchingly, I think we’re going to move from diagrams to models as the cost of those models drops, enabling deeper, model-centered system analysis. But we won’t stop there. There’s already work in model-driven system construction, and it’s not limited to security. It offers a route to generally better code, because it offers us ways to specify and build systems with a larger number of more predictable properties.
That model-centered development won’t eliminate the use of exploratory or explanatory diagrams that I discussed in the post on diagrams and clarity, but it will replace people creating diagrams with design, as-built, and as-operated diagrams being created on the fly from the system models.
